Schurter 0031.1622, FEC Shocksafe Fuseholder, 6.3 x 32 mm, Slotted Cap, 2.5 W / 10 A, Grey IP40, PLASTIC NUT (New 2024 version)
Features
- Fuseholder with high rated power acceptance - Panel thickness up to 7mm
- Screw type fuse carrier
- Slotted Type
Specification
| Schurter Part Number | 0031.1622 |
| Fuse Holder Size | 6.3 x 32mm |
| Nominal Voltage | 600VAC/DC |
| Rated Power | 2.5W/10 Amp @ 23°C |
| Nominal Current (AC/DC) | 16 Amp (VDE) 30 Amp (UL/CSA) |
| Dimensions | 10.3 x 38mm |
| Mounting Style | Panel Mount |
| Operating Temperature Range | -40°C / 85°C |
| Termination | Faston |
| IP Protection Rating | IP 40 |
| Unit Weight | 20g |
| Factory Pack Qty | 100 |
